Growatt 5kw Off-grid Single-phase Inverter Spf5000es Solar Inverter
Growatt 5kw Off-grid Single-phase Inverter Spf5000es Solar Inverter
SPF5000ES
SPF5000ES
- Integrated MPPT charge controller
- Equalization charging function
- Work with battery or without battery Maximum PV input voltage up to 450VDC
- Configurable grid or solar input priority
- Optional WlFl/ GPRS remote monitoring
Detailed Information
Product Description
Specification
| Model | SPF 3500 ES | SPF 5000 ES |
| Battery Voltage | 48VDC | |
| Battery Type | Lithium/Lead-acid | |
| Rated Power | 3500VA/ 3500W | 5000VA/ 5000W |
| Parallel Capability | Yes, 6 units maximum | |
| AC Voltage Regulation | 230VAC ± 5% @ 50/60Hz | |
| Efficiency (Peak) | 93% | |
| Waveform | Pure sine wave | |
| Charge Current | 60A | 80A |
| AC Input Voltage | 230 VAC | |
| Selectable Voltage Range | 170-280 VAC ; 90-280 VAC | |
| Frequency Range | 50Hz/60Hz (Auto sensing) | |
| Protection Degree | IP20 | |
